RF950 Surface Pumping Unit – 950 STD | 288" Stroke | 36,000 lbf Load | 350,000 in-lb Torque | Shale Green | Metric
Product Overview
The RF950 Surface Pumping Unit is a heavy-duty, separable artificial lift drive system designed for high-polished rod load applications up to 36,000 lbf. Engineered for long stroke operations (up to 288 inches), it provides reliable performance in deep, high-torque wells. Finished in Shale Green for field visibility and corrosion resistance, this ALS unit meets the operational demands of the most rugged upstream environments.
Key Features, Benefits & Advantages
-
Long Stroke Capability – 288 in / 7315.2 mm
Maximizes fluid recovery from deviated or deep wells, reducing downhole wear and increasing run time.
-
High Peak Torque Rating – 350,000 in-lb
Supports high-viscosity and high-pressure fluid lifts without mechanical strain.
-
Extreme Load Support – 36,000 lbf (160,136 N)
Ideal for heavy rod string operations and unconventional well completions.
-
Temperature Rated for Harsh Conditions
-
Operates down to -13°F / -25°C, suitable for arctic or winterized operations.
-
Field-Proven Design (RF950)
Based on the Rotaflex II platform, trusted across global basins for uptime, reliability, and efficient rod lift.
Technical Specifications
|
Parameter |
Value |
|
SKU / Item Number |
2673737 |
|
Model Designation |
RF950 |
|
Description |
WFT PU, 950 STD, Shale Green, Metric |
|
Polished Rod Load Capacity |
36,000 lbf (160,136 N) |
|
Max Stroke Length |
288 in (7315.2 mm) |
|
Peak Torque Rating |
350,000 in-lb |
|
Min Operating Temperature |
-13°F (-25°C) |
|
Unit Type |
Separable |
|
Color Requirement |
Shale Green |
|
Hazardous Classification |
None |
|
Lifecycle Status |
Released |
|
Part Source |
Make |
|
UOM |
Each |
Equipment Compatibility & Cross-Reference
-
Compatible With:
-
ALS Rotaflex II surface unit base frames
-
Heavy-duty gearboxes with 950 STD standards
-
Deep sucker rod strings, including 1.5"+ diameter systems
-
Companion & Service Parts:
-
2723164 (Service), 2706529 (Accessory), 2736814, 3072486, 3072488
-
Legacy & Internal Tracking Numbers:
-
Part Number Legacy: 2673737
-
Reference Documents: D001048213, D001048119, D001048212, D001048211
Application & Industry Use
-
Target Applications:
-
Deep and deviated wells
-
Unconventional and shale fields
-
High fluid volume artificial lift systems
-
Industry Segments:
-
Upstream Oil & Gas Production
-
ALS / Rod Lift Operations
-
Onshore and remote field developments
Certifications & Compliance
-
✅ Designed to ALS Industry Standards
-
✅ Manufactured in compliance with cost and torque classification (Level 3)
-
✅ Released lifecycle state – field ready
-
✅ Meets internal design & documentation references
Ordering & Procurement Details
-
Availability: Built-to-order with rapid release and assembly schedules
-
Lead Time: Confirmed at PO placement – expedited manufacturing options available
-
Companion Part Kitting: Available for workshop and field service units
-
Packaging: Custom rig-ready packaging and color-coded inventory system
-
Payment Terms: Net 30 / Net 60 – enterprise PO accepted
-
Support: Installation training and commissioning support available upon request
Frequently Asked Questions (FAQ)
Q1: Can this unit be field-retrofitted into existing Rotaflex II installations?
A: Yes. The RF950 follows standard ALS base dimensions for drop-in compatibility.
Q2: Is this unit suitable for corrosive environments?
A: While not coated for sour service by default, optional surface treatments and hardware substitutions are available.
Q3: Can this unit be customized in stroke length or torque rating?
A: Yes, custom mechanical configurations are available through engineering review.
Q4: Does this unit include gearbox and electric drive?
A: Gearbox/dive system is separable – request bundled part number if needed.
Q5: What is the significance of the “Shale Green” color?
A: Color-coded for field visibility, inventory classification, and safety compliance.
Call To Action (CTA)
🛠 Request a Quote for the RF950 – ALS Surface Pumping Unit
📦 Ask About Field-Ready Packaging and Companion Part Bundles
📞 Contact Engineering for Torque/Stoke Customizations
